ModelHE-S12/3
-
ColorBlue
-
Load capacity1,200 kg
-
Lifting height70 mm - 3,000 mm
-
Fork length1,150 mm
-
Speed4.2 km/h
-
Energy sourceBattery
-
BatteryLead-gel
-
Nominal capacity100 Ah
-
Battery run time4 h
-
Charging time7.5 h
-
Weight660 kg
-
Width1,148 mm
-
OperationElectric
-
Depth1,786 mm
-
Height2,280 mm - 3,549 mm
-
TiresPP
-
Gradeability4 % - 8 %
-
Turning radius1,346 mm
-
Range of applicationIndoor
- 1 x Fully powered electric straddle stacker HE-S12/3, 3.000 mm lift, WLL 1.200 kg, SolidHub
Good to know: Warehouse employees do not need any special training or a forklift licence for this. However, the person must be at least 18 years old. An introduction to handling the lifting equipment is sufficient. When working with the SolidHub electric pallet truck HE-S12/3 it is of course essential to observe and comply with the applicable legal requirements.
Before commissioning, check the national regulations applicable in the country of use. The operator is responsible for commissioning the equipment and for ensuring that suitable personnel are available for its operation.
IMPORTANT—handling the battery:
Please strictly follow the instructions for using the battery in the operating manual. It is essential never to allow the battery to become deeply discharged. The battery should therefore be charged regularly, even when the device is not being used.
-
ModelHE-S12/3
-
ColorBlue
-
Load capacity1,200 kg
-
Lifting height70 mm - 3,000 mm
-
Fork length1,150 mm
-
Speed4.2 km/h
-
Energy sourceBattery
-
BatteryLead-gel
-
Nominal capacity75 Ah
-
Battery run time4 h
-
Charging time7.5 h
-
Weight660 kg
-
Width1,148 mm
-
OperationElectric
-
Depth1,786 mm
-
Height2,280 mm - 3,549 mm
-
TiresPP
-
Gradeability4 % - 8 %
-
Turning radius1,346 mm
-
Range of applicationIndoor
- 1 x Fully powered electric straddle stacker HE-S12/3, 3.000 mm lift, WLL 1.200 kg, SolidHub
This item will be delivered by articulated lorry (40 t) with side/rear unloading. For this, a suitable lifting device (e.g., forklift) must be provided by the customer. Additional services, such as delivery via tail lift, truck-mounted forklift, or low-loader, are available at an extra charge.
At this time, SolidHub does not offer equipment with initial lift - a feature that raises the truck's wheel arms to provide additional ground clearance during load pickup and transport. However, we do have models in our line that have free lift. This feature allows the forks or load to be lifted without changing the overall height of the lift mast. An example of this is our HEF16/5 product.
To safely unload your new SolidHub stacker from the pallet, drive it off the pallet with the forks first. This will prevent damage to property or personal injury.
Our tip: Place the pallet in front of a kerb, as its height often corresponds to the height of a pallet. This allows you to drive your lifting device off the pallet almost at ground level.
Here you will find all the information you need to read a load chart.
Your order will usually be handed over to the shipping company within 24 hours of receipt of the order or payment (depending on the payment method selected), depending on stock levels. From this point on, the delivery time within Germany is a maximum of 72 hours (international shipments take correspondingly longer, please note the information directly on the respective item). If you have selected an advice note, the shipping company will contact you at least one day before delivery to arrange the delivery date.
Is your question about this product not listed and still unanswered? Submit your question and our customer service team will respond promptly! We will review your submission and reserve the right to publish it.
General questions regarding service, orders or availability are answered exclusively via the contact form, chat or email.
